Keihin PWK 28 Chrome Slides
Part Number
N502-52*00
Original Keihin chrome throttle valve slide used to limit the engine speed by closing off the main bore through the carburettor.
To fit Keihin PWK 28 carburettors.
The slide cutaway effects the mixture up to 1/4 throttle openings.
Slides are available in sizes 1, 2, 3, 3.5, 4, 5 & 6
3.5 is the standard size that comes supplied with the new carbs, if you require a leaner mixture use a larger cut away (larger number) and if you need a richer mixture use a smaller cut away (smaller number), this increases the air speed over the jets therefore pulling more fuel though them.
Part numbers:
Size | Keihin Part No | Sherco Part No | Beta Part No. |
---|---|---|---|
1 | N502-52B00 | ||
2 | N502-52C00 | ||
3 | N502-52D00 | ||
3.5 | N502-52H00 | 1326 | 3111202 000 |
4 | N502-52E00 | 1343 | 3111203 000 |
5 | N502-52F00 | ||
6 | N502-52G00 |
Manufacturer | Keihin |
---|---|
Sherco Part Code | 1326, 1343 |
Beta Part Code | 3111202 000, 3111203 000 |
