Main Jets for Keihin Carburettor

Availability: In stock

Product Name	Stock	Price
105 Main Jet for Keihin	2-5 Days	£5.49
108 Main Jet for Keihin	2-5 Days	£5.49
110 Main Jet for Keihin	9	£5.49
112 Main Jet for Keihin	9	£5.49
115 Main Jet for Keihin	4	£5.49
118 Main Jet for Keihin	7	£5.49
120 Main Jet for Keihin	4	£5.49
122 Main Jet for Keihin	7	£5.49
125 Main Jet for Keihin	7	£5.49
128 Main Jet for Keihin	2	£5.49
130 Main Jet for Keihin	2-5 Days	£5.49
135 Main Jet for Keihin	8	£5.49
140 Main Jet for Keihin	1	£5.49
152 Main Jet for Keihin	2-5 Days	£5.49
165 Main Jet for Keihin	2-5 Days	£5.49
168 Main Jet for Keihin	2-5 Days	£5.49
190 Main Jet for Keihin	2-5 Days	£5.49
195 Main Jet for Keihin	2-5 Days	£5.49
200 Main Jet for Keihin	2-5 Days	£5.49
205 Main Jet for Keihin	2-5 Days	£5.49

Add to Wishlist

Quick Overview

The Kehin PWK 28 Main Jet mainly changes the mixture on full throttle openings but changing the size of the jet also affects the mixture throughout the the full throttle range.

The most popular size main jet for trials bikes in the UK is a 125, warmer climates or higher altitudes have less oxygen in the air so require smaller jets.

Also fits CR, FCR, PJ, PWK, PWM, PE, PD Keihin Carbs.

Keihin Main Jet

Double click on above image to view full picture

Details

The number of the jet indicates the size of the hole (highest is the largest/richest). Too rich a mixture will limit the maximum engine speed, too lean a mixture will cause seizure so it is often best to stay slightly on the too rich side. Part numbers:

Size	Keihin Part No	Sherco Part No	Beta Part No
105	99101-357-105		1642301 000
108	99101-357-108		1642303 000
110	99101-357-110		1642305 000
112	99101-357-112		1642302 000
115	99101-357-115	1402	1642306 000
118	99101-357-118	1352	1642304 000
120	99101-357-120	1353	1642307 000
122	99101-357-122	1248	1642308 000
125	99101-357-125	1247	1642309 000
128	99101-357-128		1642310 000
130	99101-357-130		1642311 000
135	99101-357-135
152	99101-357-152
165	99101-357-165
168	99101-357-168
190	99101-357-190
195	99101-357-195
200	99101-357-200
205	99101-357-205

Additional Information

Manufacturer	Keihin
Sherco Part Code	1247, 1248, 1347, 1352, 1353, 1402
Beta Part Code	1642301 000, 1642303 000, 1642305 000, 1642302 000, 1642306 000, 1642304 000, 1642307 000, 1642308 000, 1642309 000, 1642310 000, 1642311 000
Year	2007, 2008, 2009
Model	320

99101-357-***
