Olle / R16V Rear Shock Springs

Part Number
ROLLE_SPRING
Grouped product items
Product Name Price Qty
Olle Spring 63N/mm (Black)
0 in stock - Available to order
£80.64
Olle Spring 70N/mm
8 in stock
£69.95
Olle/R16V Spring 6.5 to 7.8 kg/mm progressive spring
£69.95
Out of stock
Olle/R16V Spring 81N/mm (Black)
4 in stock
£69.95

Springs to fit the Olle and R16V rear shock absorbers found on the following trials bikes:

Sherco from 2006 to present (standard and Racing models only).
Montesa 4RT from 2014 to present (standard model only).
Montesa 4Ride.
TRS One 2016 to 2018.
Jotagas.
Scorpa Twenty 2015 to present (Standard and Race models only).
Beta Evo Factory 2017 to present (Factory models only with the R16V shock).

Also fits the aftermarket Olle shocks for the Beta Evo.

The 63N/mm spring is the standard spring fitted to the 2012 onwards Shercos with the R16V rear shocks.

The progressive 64 to 76.5N/mm spring came as standard on the 2006 to 2007 Shercos.

The 70N/mm spring is the standard weight spring that comes on the 2014 onwards Montesa 4RT and the Sherco trials bikes from 2008 to 2011.  This spring has come in red, yellow, black & white over the years.

The 81N/mm spring is the standard spring fitted to the Montesa 4Ride.

Please see here for fitting a spring to an Olle shock

Rough Dimensions:
Internal diameter 43-44mm
Length 130-132mm

Spring Recommendations

Bike  \  Spring63N/mm64-76.5N/mm70N/mm81N/mm
Sherco 2012 onwards Standard (11 to 13 stone) Progressive Stiffer (14 to 16 stone) Very Stiff (16 stone upwards)
2006 to 2007 Sherco Soft (11 stone and under) Standard (12 to 13 stone) Stiffer (14 stone upwards)
2008 to 2011 Sherco
Beta Evo with Olle or R16V shock
Montesa 4RT Std 2014 on
TRS One Std 2016 on
Soft (11 stone and under) Standard (11 to 13 stone) Stiffer (14 stone upwards)
Montesa 4Ride Very Soft (10 stone and under) Soft (11 stone) Standard (11 to 13 stone)
More Information
Manufacturer Olle
Sherco Part Code 1760, 3645, 3545
Beta Part Code 007.33.097.00.53 To Fit: 007.33.088.80.00, 008.33.004.80.00, 007.33.094.80.00, 008.33.005.80.00, 007.33.111.80.00, 008.33.006.80.00, 007.33.119.80.00, 008.33.007.80.00
JotaGas / JGas Part To fit: 0502351, T30C000501
Scorpa Part Code 3545
Montesa / Honda Part 52401-NN4-J10
EM Part Code TL01K-30402-00-00, TL01J-30401-R3-ASM, TL01J-30401-R1-ASM, TL01J-30401-R2-ASM
TRS Part Code 70504
Year 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022
Model 125, 200, 250, 290, 300
