Stator repair exchange - Sherco - 2002 to 2005

Testing and checking your Sherco stator plates, only applicable to the Leonelli stators from 2002 to 2007.

The trigger, using the diode check mode on a multi meter, you should get reading something like this, don't worry about exact numbers if it is somewhere in the same region.

Using the red lead to the plug terminals and black to earth.
Blue no reading (sometimes shown as 1 or error)
Brown 1000 to 1600
Black 1050 to 1650

Using the leads the other way around i.e. black lead to the coloured wires, red to earth.
Blue 600 to 730
Brown 650 to 770
Black 650 to 770

Also test the resistance's of the other coil wires, leads either way around.
White to red 95 ohms
Red to green 550 ohms
Green to white 640 ohms

After ordering please remove your stator and send it to:

SplatShop
Unit 3, Broombank Park,
Sheepbridge,
Chesterfield
S41 9RT
UK.

Make sure that you include a note with your stator with your name, address and contact number.
If we have a repaired stator in stock ready to send, we will send it as soon as we receive yours.
