Regina 520 Split Links
Spare chain split link to fit the Regina 520 chain.
The split link tends to be the first link that wears out on a chain resulting in a ticking noise each time it hits the front sprocket, replacing this link may increase the usable life of the chain.
EBX Gold is the new version of the EBXL chain, EBX Gold split link fits the EBXL Black chains.
Also handy to have as a spare just in case they come off midway through a trial.
There are 2 different 520 Regina Chains used on trials bikes. Please see the table below for the differences:
| Chain Type | Pin Length (mm) |
Plate Thickness (mm) |
|---|---|---|
| 135 EBXL / EBX | 16.6 | 1.6 |
| 135 EBORO | 17.3 | 1.8 |
The EBXL comes as standard on new Sherco, Beta, Vertigo & Montesa bikes, the EBX chain is the same as the EBXL but with Gold links. The EBSORO / EBORO is the cheaper and heavier Gold linked chain.
| Manufacturer | Regina |
|---|---|
| Sherco Part Code | R034 (EBXL) |
| Beta Part Code | 22-11220, 002211220000 (EBXL) |
| Montesa / Honda Part | 40531-NN2-000 (EBXL) |
-
