Ohlins Rear Shock Springs
Part Number
OhlinsSpring
To fit Ohlins rear trials shock, customise your shock to your weight. See the table below for details on what spring suits which weights.
The 65, 70, 75, 80, 90, 100 and the progressive 62-74 N/mm are genuine Ohlins springs but unfortunately Ohlins don't make the 47.5 and 55N/mm option so these 2 options are made to the Ohlins technicians own specs to fill the gap between the 40 and 65 springs.
Spring stiffness guide based on rider weight
|
Spring Rate |
47.5 N/mm |
55 N/mm |
65 N/mm |
Progresive 62-74 N/mm |
Standard 70 N/mm |
75 N/mm |
80 N/mm |
|
Part number |
125S47.5N |
125S55N |
281-64 |
281-09 |
281-15 |
281-16 |
281-14 |
|
Rider Weight (KG) |
60-70 |
70 |
80-90 |
93-105 |
|||
|
50-60 |
70-80
|
90
|
85-95 |
||||
|
Stones |
8 - 9.5 |
9.5 - 11 |
11 - 12.5 |
11 - 12.5 |
12.5 - 14 |
13.5 - 15 |
14.5 - 17 |
Dimensions
The spring is roughly 124mm long. (100N/mm is 135mm long).
65mm to 70mm outer diameter depending on the spring rate.
46mm inner diameter.
| Manufacturer | Ohlins |
|---|
