Dellorto VHST Pilot Jets
Part Number
E16690.**.02_E17014.**.02
The Dellorto pilot jet changes the mixture at idle speed up to about a 1/4 throttle openings.
The most popular size pilot jet for trials bikes in the UK is around a 35, warmer climates or higher altitudes have less oxygen in the air so require smaller jets.
Fits VHST Dellorto Carburettors
The S style jets developed for use with the 2 stroke bikes, they have smaller holes in the atomiser tube that let less air through than the U type, this gives a slightly richer mixture.
The U style was developed for use with the 4 stroke bikes (although it can happily be used in a two stroke), it has larger holes in the atomiser tube giving a slightly weaker mixture. The U jets give a similar mixture to a S jet of 2 or 3 sizes smaller.
The most popular size pilot jet for trials bikes in the UK is around a 35, warmer climates or higher altitudes have less oxygen in the air so require smaller jets.
Fits VHST Dellorto Carburettors
The S style jets developed for use with the 2 stroke bikes, they have smaller holes in the atomiser tube that let less air through than the U type, this gives a slightly richer mixture.
The U style was developed for use with the 4 stroke bikes (although it can happily be used in a two stroke), it has larger holes in the atomiser tube giving a slightly weaker mixture. The U jets give a similar mixture to a S jet of 2 or 3 sizes smaller.
The number of the jet indicates the size of the hole (highest is the largest/richest).
Part numbers:
Size | Dellorto Part No. | Sherco Part No. | GasGas Part No. |
---|---|---|---|
S32 | 16690.32 | ||
S33 | 16690.33 | ||
S34 | 16690.34 | ||
S35 | 16690.35 | ||
S36 | 16690.36 | MT280390019 | |
S37 | 16690.37 | ||
S38 | 16690.38 | ||
S39 | 16690.39 | ||
S40 | 16690.40 | ||
U32 | 17014.32 | ||
U33 | 17014.33 | ||
U34 | 17014.34 | ||
U35 | 17014.35 | ||
U36 | 17014.36 | ||
U37 | 17014.37 |
Manufacturer | Dellorto |
---|---|
GasGas Part Code | MT280390019 |
